Customized Vehicle Exhaust System Pipe fitting Titanium 90 Degree Elbow
-
Highlight
custom titanium exhaust pipe fitting
,titanium 180 degree exhaust elbow
,vehicle exhaust system titanium fitting
-
MaterialTA1,TA2, Gr.1 BT1-00, Gr.1ELI, BT1－00CB,Gr.2 BT1-0 Etc
-
SizeDN15-DN 650(NPS1/2-NPS 26)
-
OEM/ODMAvailable
-
Titanium Surface FinishInner And Outer Surface Polishing
-
TechnicsWelding
-
TypeTitanium 90° Sanitary Elbow
-
Place of OriginShaanxi,China
-
Brand NameVOTECH
-
CertificationGB/T17684—2011，ASME B 16.9
-
Model NumberDN15-DN 650(NPS1/2-NPS 26)
-
Packaging DetailsExport Standard Wooden Case, or Can Be Customized
-
Delivery Time7-15 Days
-
Payment TermsMoneyGram,Western Union,T/T,D/P,D/A,L/C
-
Supply Ability100ton/Month
Customized Vehicle Exhaust System Pipe fitting Titanium 90 Degree Elbow
Customized Vehicle Exhaust System Pipe Fitting Titanium 90 Degree Elbow
The Titanium 90° sanitary elbow is a specialized pipe fitting designed to change the direction of fluid flow in pipeline systems. Engineered for demanding sanitary-sensitive applications, it is widely used across industries including dairy, food and beverage, beer production, biopharmaceutical, and daily chemicals.
Available in specifications from DN15 to DN650, our Titanium 90° Sanitary Elbow fittings can also be custom-manufactured to customer specifications or drawings. All products are manufactured in strict compliance with international standards including ASME B16.9 and GB/T 17684-2011 to meet global customer requirements.
This 90° sanitary titanium elbow ensures media purity through exceptional corrosion resistance, high-temperature tolerance, superior strength, and lightweight properties. With a lifespan significantly exceeding stainless steel alternatives, it is the ideal choice for high-sanitation process connections in food processing and pharmaceutical applications.
Product Specifications
| Standard | GB/T17684--2011, ASME B 16.9 |
|---|---|
| Material | TA1, TA2, Gr.1 BT1-00, Gr.1ELI, BT1-00CB, Gr.2 BT1-0 etc |
| Size | DN15-DN 650 (NPS1/2-NPS 26) |
| OEM/ODM | Available |
| Titanium Surface Finish | Inner and Outer Surface Polishing |
| Technics | Welding |
| Type | Titanium 90° sanitary elbow |
| Packaging | Export standard wooden case, or can be customized |
| Application | Pharmaceutical Industry, Biotechnology & Biopharm, Food & Beverage Industry, Cosmetics Industry, Semiconductor & Electronics Industry, Chemical & Speciality Chemicals, Vehicle Exhaust System |
Dimensional Specifications (mm)
|
Nominal size |
|
Center to End |
Center to Center |
Back to Face |
|||||
|
90°Ebows |
45°Ebows |
180°return |
|||||||
|
DN |
NPS |
D |
LR |
SR |
LR |
LR |
SR |
LR |
SR |
|
15 |
1/2 |
21.3 |
38 |
- |
16 |
76 |
- |
48 |
- |
|
20 |
3/4 |
26.7 |
38 |
- |
19 |
76 |
- |
51 |
- |
|
25 |
1 |
33.4 |
38 |
25 |
22 |
75 |
51 |
56 |
41 |
|
32 |
1 1/4 |
42.2 |
48 |
32 |
25 |
95 |
64 |
70 |
52 |
|
40 |
1 1/2 |
48.3 |
57 |
38 |
29 |
114 |
76 |
83 |
62 |
|
50 |
2 |
60.3 |
76 |
51 |
35 |
152 |
102 |
106 |
81 |
|
65 |
2 1/2 |
73.0 |
95 |
64 |
44 |
191 |
127 |
132 |
100 |
|
80 |
3 |
88.9 |
114 |
76 |
51 |
229 |
152 |
159 |
121 |
|
90 |
3 1/2 |
101.6 |
133 |
89 |
57 |
267 |
178 |
184 |
140 |
|
100 |
4 |
114.3 |
152 |
102 |
64 |
305 |
203 |
210 |
159 |
|
125 |
5 |
141.3 |
190 |
127 |
79 |
381 |
254 |
262 |
197 |
|
150 |
6 |
168.3 |
229 |
152 |
95 |
457 |
305 |
313 |
237 |
|
200 |
8 |
219.1 |
305 |
203 |
127 |
610 |
406 |
414 |
313 |
|
250 |
10 |
273 |
381 |
254 |
159 |
762 |
508 |
518 |
391 |
|
300 |
12 |
323.8 |
457 |
305 |
190 |
914 |
609 |
619 |
467 |
|
350 |
14 |
355.6 |
533 |
356 |
222 |
1067 |
711 |
711 |
533 |
|
400 |
16 |
406.4 |
610 |
406 |
254 |
1219 |
813 |
813 |
610 |
|
450 |
18 |
457.0 |
686 |
457 |
286 |
1372 |
914 |
914 |
686 |
|
500 |
20 |
508.0 |
762 |
508 |
318 |
1524 |
1016 |
1016 |
762 |
|
550 |
22 |
559.0 |
838 |
559 |
343 |
1676 |
1118 |
1118 |
838 |
Frequently Asked Questions
What are the outstanding performances of titanium 90° sanitary elbow in terms of corrosion resistance?
Titanium pipe fittings exhibit exceptional resistance to corrosive media including seawater and chloride ions. Their corrosion resistance significantly surpasses stainless steel and carbon steel, making them particularly suitable for harsh environments such as marine and chemical industries.
Do titanium 90° sanitary elbows need additional anti-rust measures?
No additional protection is required. Titanium 90° sanitary elbows can be used long-term without coatings or cathodic protection, eliminating rust risk and significantly reducing maintenance requirements.
Where does the lightweight advantage of titanium 90° sanitary elbows lie?
Titanium offers strength comparable to steel with only 60% of the density. This enables significant weight reduction in applications like aerospace and shipbuilding while maintaining high load-bearing capacity.
How is the high-temperature resistance of titanium pipe fittings?
Titanium alloys (including TA2 and TA9) maintain stable mechanical properties at 300-500°C, with some materials capable of withstanding even higher temperatures for short durations.
Why are titanium 90 degree sanitary elbows still economical despite their high initial cost?
While the initial investment is higher, titanium fittings offer extremely long service life and minimal maintenance requirements, resulting in superior long-term cost-effectiveness.
Are titanium pipe fittings suitable for the pharmaceutical and food industries?
Absolutely. Titanium's non-toxic, biocompatible properties and high material purity meet the stringent hygiene requirements of pharmaceutical and food processing applications.
Our Manufacturing Advantages
1. Strict Quality Control
We implement rigorous quality measures compliant with ASME, JIS, DIN, GB, and GOST standards, ensuring every titanium product meets industry and customer specifications.
2. Modern Production Facilities
Our advanced factory features multiple titanium metal production lines, enabling efficient handling of bulk orders and customized projects.
3. Secure Logistics & Packaging
Every order is carefully packed in wooden crates or trays to prevent transit damage, ensuring maximum protection and safety.
4. Experienced Team
With years of specialized knowledge in titanium manufacturing, we understand the nuances of producing high-quality products for diverse industries.
5. Comprehensive Service
We provide customized solutions, fast lead times, and dedicated support throughout your purchasing process.
6. Customer-Centric Approach
We offer flexible payment options, complete technical support, and dedicated customer service for a seamless purchasing experience.
