Master Wear Plug for NOGO Ring Gauges Calibration Tool
-
Highlight
NOGO ring gauge plug
,metric plug thread gauge
,ring gauge calibration tool
-
WarrantyOne Year
-
Product TypeMaster Wear Plug Gauge
-
Gauge TypeNOGO Gauge (for Checking Ring Gauge Wear)
-
ApplicationFor Calibration And Wear Verification Of GO Ring Gauges
-
Gauge MaterialTool Steel
-
Surface TreatmentPrecision Ground And Lapped To Mirror Finish
-
Storage CasePlastic Case
-
Place of OriginShaanxi, China
-
Brand NameKM
-
CertificationISO DIN GB RoHS
-
Model NumberKM-CPR650-200-8G-NG
-
Packaging DetailsPlastic Case 14.5*7.5*7.5cm/Piece 0.70kg/Piece
-
Delivery TimeWithin 15days
-
Payment TermsL/C,D/A,D/P,T/T,Western Union,MoneyGram
-
Supply Ability50000pieces/Month
Master Wear Plug for NOGO Ring Gauges Calibration Tool
Master wear plug gauges are precision tools used to monitor and ensure the wear condition of ring gauges during manufacturing.
These gauges are used to check the fit and wear of ring gauges, ensuring they meet specifications and maintain quality during production.
Master wear plug gauge are made of bearing steel, providing high strength and resistance to wear.
When you order, please kindly mention example: M65x2 8g master wear plug gauge for NoGo Ring.
- Master wear plug gauge for precision measurement.
- Available in various accuracy grades: 6g, 8g, etc.
- Types include GO, NO GO, and combination GO/NOGO.
- Wear and corrosion resistant bearing steel construction.
- Stable structure for reliable performance.
- Supplied in protective fitted case.
|
Order No. |
Size |
Coarse |
Fine |
Accuracy |
||||
|
Pitch 1 |
Pitch 1 |
Pitch 1 |
Pitch 1 |
Pitch 1 |
Pitch 1 |
|||
|
KM-R001 |
M1.0 |
0.25 |
0.20 |
|
|
|
|
3h 4h 5g6g 5h4h 5h6h 6e 6f 6g 6h 7g6g 7h6h 8g 8h |
|
KM-R011 |
M1.1 |
0.25 |
0.20 |
|
|
|
|
|
|
KM-R012 |
M1.2 |
0.25 |
0.20 |
|
|
|
|
|
|
KM-R014 |
M1.4 |
0.30 |
0.20 |
|
|
|
|
|
|
KM-R016 |
M1.6 |
0.35 |
0.20 |
|
|
|
|
|
|
KM-R018 |
M1.8 |
0.35 |
0.20 |
|
|
|
|
|
|
KM-R020 |
M2.0 |
0.40 |
0.25 |
|
|
|
|
|
|
KM-R022 |
M2.2 |
0.45 |
0.25 |
|
|
|
|
|
|
KM-R025 |
M2.5 |
0.45 |
0.35 |
|
|
|
|
|
|
KM-R030 |
M3.0 |
0.50 |
0.35 |
|
|
|
|
|
|
KM-R035 |
M3.5 |
0.60 |
0.35 |
|
|
|
|
|
|
KM-R040 |
M4.0 |
0.70 |
0.50 |
|
|
|
|
|
|
KM-R050 |
M5.0 |
0.80 |
0.50 |
|
|
|
|
|
|
KM-R060 |
M6.0 |
1.00 |
0.75 |
0.50 |
|
|
|
|
|
KM-R080 |
M8.0 |
1.25 |
1.00 |
0.75 |
0.50 |
|
|
|
|
KM-R100 |
M10.0 |
1.50 |
1.25 |
1.00 |
0.75 |
0.50 |
|
|
|
KM-R120 |
M12.0 |
1.75 |
1.50 |
1.25 |
1.00 |
0.75 |
0.50 |
|
|
KM-R140 |
M14.0 |
2.00 |
1.50 |
1.25 |
1.00 |
0.75 |
0.50 |
|
|
KM-R160 |
M16.0 |
2.00 |
1.50 |
1.00 |
0.75 |
0.50 |
|
|
|
KM-R180 |
M18.0 |
2.50 |
2.00 |
1.50 |
1.00 |
0.75 |
0.50 |
|
|
|
…… |
…… |
…… |
…… |
…… |
…… |
…… |
|
|
KM-R320 |
M320 |
|
|
|
|
|
|
|
Master wear plug gauges are used for the manufacture and checking wear condition of ring gauges. They are essential in industries
where precision and consistency in measurements are critical.
- Inspect the measuring surface for cleanliness, rust, or scratches before use.
- Ensure all markings are clearly visible.
- Use only during valid inspection periods with proper documentation.
- Maintain measurement temperature close to 20°C.
- Apply minimal force - avoid pushing or rotating the gauge.
- Insert and remove along the axis without tilting.
- Clean thoroughly after each use to maintain accuracy.
