25-30mm Pistol-grip Three Point Internal Micrometers For Accurate Bore Measuring

25-30mm Pistol-grip Three Point Internal Micrometers for Accurate Bore Measuring

Quick Detail:
1. Self-centering 3-point for accurate bore measuring.
2. Measurement can be taken closer to the bottom of the blind bore.
3. Carbide-tipped contacts points, ratchet stop.
4. Digital indicator is optional. Fixing bore for digital indicator:φ8mm or 3/8’’.
5. Within 100mm, supplied with setting rings.
6. Supplied in fitted case.

Description:
This series is pistol-grip three-point bore micrometer, supplied measuring range from 6-8mm up to 275-300mm.
The pistol design allows us to operate the micrometer with one hand, making it easy to measure in tight spaces
or hard-to-reach locations, and is suitable for batch measurements, allowing for quick comparison of the dimensions
of multiple holes to verify consistency.

This three contact points allow the micrometer to be more accurate and stable when measuring blind and through holes.
With three-point contact, the errors in the measurement process can be avoided more effectively, thus improving the accuracy
of the measurement results.

We also supply set with a wide measuring range.


Specification:


Precautions:
1. Do not apply excessive force to keep precise measuring when measuring.
2. Do not disassemble the instrument.
3. Keep the instrument clean and dry.
4. When install measuring jaws, pull back the grip of pistol and insert the measuring jaws into the grooves
    in the measuring head in turn. Inspect whether the measuring jaws by smaller pull.
5. When changing the measuring jaws, number of the measuring jaws must fit the relevant that of the three grooves
    in the measuring head.
6. Return into the packaging box after apply anti-rust oil if not used for a long time.
7. Prevent dust from getting inside the three grooves in the measuring head.
8. Digital indicator with range of above 12.7mm/0.5'' is suggested to install with the pistol-grip three-point
    internal micrometers for use.

Applications:
Pistol-grip three-point internal micrometer is mainly used to measure the holes, slotted hole, etc. It is widely used in machinery
manufacturing, automobile manufacturing, aerospace, electronic components and other industrial fields.
With its high measurement accuracy, easy to use and simple operation, it has become one of the important tools
for measuring bore diameter.
FAQ:
1) Who are we?
Deko Corporation mainly dedicate to the development, manufacture and marketing of KM brand precision measuring tools
in China mainland.

2) What products do we carry?
Dial indicators, micrometers, calipers, bore gauges, height gauges, dial thickness gauges, depth gauges, bevel protractors,
gauge, blocks, level, etc.

3) What are the terms of trade?
We support FOB, CFR, CIF, EXW.

4) What are the forms of payment?
We accept T/T, L/C, D/A, D/P, PayPal, Western Union.

5) Do we accept customization?
Yes, OEM is available.

6) How about after-sales service?
One year warranty for all kinds of products.
If you find any defective accessories when receive goods, we will ship your news parts or new product to replace.
As an experienced manufacturer, we have very strict calibration and inspection team, you can rest assured of our product quality.
