Precision 175-200mm Rod Inside Micrometer for Deep Internal Bore Diameter Measurement
-
Highlight
Deep Internal Bore Diameter Micrometer
,175-200mm Deep Internal Bore Micrometer
-
WarrantyOne Year
-
MeasurementMetric
-
Measurement ObjectRod Inside Micrometer
-
Range175-200mm
-
Accuracy0.007mm
-
Graduation0.01mm
-
Diameter Of Extension Rods12mm
-
FeatureEasy To Operate
-
PackageWooden Box
-
Place of OriginShaanxi, China
-
Brand NameKM
-
CertificationISO DIN GB RoHS
-
Model NumberKM-3306-200
-
Packaging DetailsWood Box 20*15*6cm/Piece 1.25kg/Piece
-
Delivery TimeWithin 15days
-
Payment TermsT/T,L/C,D/P,D/A,Western Union,PayPal,MoneyGram
-
Supply Ability50000pieces/Month
Precision 175-200mm Rod Inside Micrometer for Deep Internal Bore Diameter Measurement
Precision 175-200mm Rod Inside Micrometer for Deep Internal Bore Diameter Measurement
This series provides single rod type inside micrometers with a locking clamp and 16mm diameter extension rods. The hardened and ground spindle along with carbide anvil ensure durability and accuracy for easy operation and high precision measurement.
We supply a full measuring range from 50mm up to 1000mm for metric measurement, and 2" up to 40" for inch measurement. Each unit comes with a key wrench in a protective case.
Our inside micrometers are manufactured under strict ISO 9001 standards and inspected with calibrated measuring equipment traceable to national/international standards.
Key Features:
- Single rod type inside micrometer
- Carbide measuring faces
- Diameter of extension rods: 16mm
- Supplied in fitted case
Metric Specifications:
| Order No. | Measuring Range | Accuracy | Order No. | Measuring Range | Accuracy |
|---|---|---|---|---|---|
| KM-3306-75 | 50-75mm | 0.005mm | KM-3306-550 | 525-550mm | 0.011mm |
| KM-3306-100 | 75-100mm | 0.005mm | KM-3306-575 | 550-575mm | 0.011mm |
| KM-3306-125 | 100-125mm | 0.006mm | KM-3306-600 | 575-600mm | 0.012mm |
| KM-3306-150 | 125-150mm | 0.006mm | KM-3306-625 | 600-625mm | 0.012mm |
| KM-3306-175 | 150-175mm | 0.007mm | KM-3306-650 | 625-650mm | 0.012mm |
| KM-3306-200 | 175-200mm | 0.007mm | KM-3306-675 | 650-675mm | 0.013mm |
| KM-3306-225 | 200-225mm | 0.008mm | KM-3306-700 | 675-700mm | 0.013mm |
| KM-3306-250 | 225-250mm | 0.008mm | KM-3306-725 | 700-725mm | 0.013mm |
| KM-3306-275 | 250-275mm | 0.009mm | KM-3306-750 | 725-750mm | 0.014mm |
| KM-3306-300 | 275-300mm | 0.009mm | KM-3306-775 | 750-775mm | 0.014mm |
| KM-3306-325 | 300-325mm | 0.009mm | KM-3306-800 | 775-800mm | 0.014mm |
| KM-3306-350 | 325-350mm | 0.009mm | KM-3306-825 | 800-825mm | 0.015mm |
| KM-3306-375 | 350-375mm | 0.010mm | KM-3306-850 | 825-850mm | 0.015mm |
| KM-3306-400 | 375-400mm | 0.010mm | KM-3306-875 | 850-875mm | 0.015mm |
| KM-3306-425 | 400-425mm | 0.010mm | KM-3306-900 | 875-900mm | 0.016mm |
| KM-3306-450 | 425-450mm | 0.010mm | KM-3306-925 | 900-925mm | 0.016mm |
| KM-3306-475 | 450-475mm | 0.011mm | KM-3306-950 | 925-950mm | 0.016mm |
| KM-3306-500 | 475-500mm | 0.011mm | KM-3306-975 | 952-975mm | 0.017mm |
| KM-3306-525 | 500-525mm | 0.011mm | KM-3306-1000 | 975-1000mm | 0.017mm |
Inch Specifications:
| Order No. | Measuring Range | Accuracy | Order No. | Measuring Range | Accuracy |
|---|---|---|---|---|---|
| KM-3306-3 | 2-3" | 0.00020" | KM-3306-22 | 21-22" | 0.00043" |
| KM-3306-4 | 3-4" | 0.00020" | KM-3306-23 | 22-23" | 0.00043" |
| KM-3306-5 | 4-5" | 0.00024" | KM-3306-24 | 23-24" | 0.00047" |
| KM-3306-6 | 5-6" | 0.00024" | KM-3306-25 | 24-25" | 0.00047" |
| KM-3306-7 | 6-7" | 0.00028" | KM-3306-26 | 25-26" | 0.00047" |
| KM-3306-8 | 7-8" | 0.00028" | KM-3306-27 | 26-27" | 0.00051" |
| KM-3306-9 | 8-9" | 0.00032" | KM-3306-28 | 27-28" | 0.00051" |
| KM-3306-10 | 9-10" | 0.00032" | KM-3306-29 | 28-29" | 0.00051" |
| KM-3306-11 | 10-11" | 0.00036" | KM-3306-30 | 29-30" | 0.00055" |
| KM-3306-12 | 11-12" | 0.00036" | KM-3306-31 | 30-31" | 0.00055" |
| KM-3306-13 | 12-13" | 0.00036" | KM-3306-32 | 31-32" | 0.00055" |
| KM-3306-14 | 13-14" | 0.00036" | KM-3306-33 | 32-33" | 0.00059" |
| KM-3306-15 | 14-15" | 0.00040" | KM-3306-34 | 33-34" | 0.00059" |
| KM-3306-16 | 15-16" | 0.00040" | KM-3306-35 | 34-35" | 0.00059" |
| KM-3306-17 | 16-17" | 0.00040" | KM-3306-36 | 35-36" | 0.00063" |
| KM-3306-18 | 17-18" | 0.00040" | KM-3306-37 | 36-37" | 0.00063" |
| KM-3306-19 | 18-19" | 0.00043" | KM-3306-38 | 37-38" | 0.00063" |
| KM-3306-20 | 19-20" | 0.00043" | KM-3306-39 | 38-39" | 0.00067" |
| KM-3306-21 | 20-21" | 0.00043" | KM-3306-40 | 39-40" | 0.00067" |
Packaging & Shipping
Company Profile:
Applications
Single Type inside micrometers are precision measuring instruments especially useful for measuring the inside diameter of pipes, tubes, and other cylindrical objects with narrow openings. They are essential for quality control in manufacturing, automotive, and construction industries.
Precautions
- Check whether the zero line is accurate before use
- Clean the measuring surface of the workpiece during measurement
- Wipe the measuring rod and anvil clean before measuring
- Use ratchet device when screwing the movable sleeve
- Do not loosen the back cover to prevent zero line changes
- Do not add ordinary engine oil between fixed and movable sleeves
- After use, clean, oil, and store in fitted case in dry place
Frequently Asked Questions
Who are we?
Deko Corporation specializes in the development, manufacture and marketing of KM brand precision measuring tools in China mainland.
What products do we carry?
Dial indicators, micrometers, calipers, bore gauges, height gauges, dial thickness gauges, depth gauges, bevel protractors, gauge blocks, levels, and more.
What are the terms of trade?
We support FOB, CFR, CIF, and EXW trade terms.
What are the forms of payment?
We accept T/T, L/C, D/A, D/P, PayPal, and Western Union.
Do we accept customization?
Yes, OEM services are available.
How about after-sales service?
All products come with one year warranty. If you receive any defective accessories, we will ship replacement parts or products. Our strict calibration and inspection processes ensure product quality you can trust.
