Internal Electronic Caliper Gage for Accurate Measurements of Internal dimensions

Internal Electronic Caliper Gage for Accurate Measurements of Internal dimensions

Products - Caliper Gauges
  • Highlight

    0-30mm digital inside caliper

    ,

    internal groove measuring gauge

    ,

    digital bore caliper with warranty

  • Warranty
    One Year
  • Type
    Digital Internal Caliper Gauge
  • Measurement Object
    Inside Diameter
  • Measurement
    Metric/Inch
  • Range
    40-50mm
  • Accuracy
    0.03mm
  • Anvil Type
    Flat
  • Resolution
    0.005mm
  • Jaw Design
    Parallel Jaws
  • Customization
    Customized
  • Package
    Aluminum Box
  • Place of Origin
    Shaanxi, China
  • Brand Name
    KM
  • Certification
    ISO DIN GB RoHS
  • Model Number
    KM-320A-50
  • Packaging Details
    Aluminum Box 30*16*5.5cm/Piece 1.10kg/Piece
  • Delivery Time
    Within 15days
  • Payment Terms
    L/C,D/A,D/P,T/T,Western Union,MoneyGram
  • Supply Ability
    50000pieces/Month

Internal Electronic Caliper Gage for Accurate Measurements of Internal dimensions

  • Internal Electronic Caliper Gage for Accurate Measurements of Internal dimensions
  • Internal Electronic Caliper Gage for Accurate Measurements of Internal dimensions
  • Internal Electronic Caliper Gage for Accurate Measurements of Internal dimensions
  • Internal Electronic Caliper Gage for Accurate Measurements of Internal dimensions
  • Internal Electronic Caliper Gage for Accurate Measurements of Internal dimensions
  • Internal Electronic Caliper Gage for Accurate Measurements of Internal dimensions
Get Price Contact Now
Internal Electronic Caliper Gage for Accurate Measurements of Internal Dimensions
Description

Digital inside caliper gauge is precision inside caliper gauge equipped with a digital indicator and spring-loaded arms fixed to the digital indicator

that measures inside dimensions. It mainly used to measure the internal diameter of objects with high accuracy and repeatability.

The digital display can indicate both metric and inch measurement.



Electronic digital caliper gauge are manufactured with high-quality materials and precise processes for high durability and stability.

Even in harsh working environments, it can maintain stable operation for a long time.

Internal digital caliper gauge is a reliable and essential tool for anyone who needs to measure the internal diameter of objects with precision

and accuracy. Their digital readout display provides a fast and accurate way to obtain measurements, making them ideal for applications

where time and precision are both important factors.

Key Features
  • Large LCD digital display for easy reading.
  • Measures bores, internal grooves, and other hard-to-reach inside dimensions.
  • Dial rotates ±170° for use at various angles.
  • Retains origin data of absolute measurement after battery change.
  • Dual digital and analog display on LCD with automatic switchover.
  • Analog display range: ±20 graduation.
  • Available with A type and B type measuring faces.
  • Power ON/OFF function.
  • ABS and INC conversion capability.
  • Metric and Inch conversion.
  • Origin data set function.
  • Tolerance set capability.
  • Memory function for max/min data or hold display data.
  • Data output capability.
  • Supplied in fitted case.
Specifications:
Metric:
Order No. Range Resolution Accuracy Measuring Contact Forms
KM-320A-25 5~25mm 0.005mm 0.03mm Internal Electronic Caliper Gage for Accurate Measurements of Internal dimensions 0
KM-320A-30 10~30mm 0.005mm 0.03mm
KM-320A-40 20~40mm 0.005mm 0.03mm
KM-320A-50 30~50mm 0.005mm 0.03mm
KM-320A-60 40~60mm 0.005mm 0.03mm Internal Electronic Caliper Gage for Accurate Measurements of Internal dimensions 1
KM-320B-30 10~30mm 0.005mm 0.03mm
KM-320B-40 20~40mm 0.005mm 0.03mm
KM-320B-50 30~50mm 0.005mm 0.03mm
KM-320B-60 40~60mm 0.005mm 0.03mm
Inch:
Order No. Range Resolution Accuracy Measuring Contact Forms
KM-320A-1.0 0.2~1.0″ 0.0002″ 0.0012″ Internal Electronic Caliper Gage for Accurate Measurements of Internal dimensions 2
KM-320A-1.2 0.4~1.2″ 0.0002″ 0.0012″
KM-320A-1.6 0.8~1.6″ 0.0002″ 0.0012″
KM-320A-2.0 1.2~2.0″ 0.0002″ 0.0012″
KM-320A-2.4 1.6~2.4″ 0.0002″ 0.0012″
KM-320B-1.2 0.4~1.2″ 0.0002″ 0.0012″ Internal Electronic Caliper Gage for Accurate Measurements of Internal dimensions 3
KM-320B-1.6 0.8~1.6″ 0.0002″ 0.0012″
KM-320B-2.0 1.2~2.0″ 0.0002″ 0.0012″
KM-320B-2.4 1.6~2.4″ 0.0002″ 0.0012″
Applications
Digital inside caliper gauges are suitable for measuring inside dimensions in various industries including mechanical manufacturing,
metal manufacturing, automobile manufacturing, and aerospace.
Precautions
  • Do not subject the gauge to blows or knocks.
  • Do not drop the gauge or apply excessive force..
  • Do not disassemble the gauge.
  • Do not press buttons with pointed objects.
  • Avoid direct sunlight and extreme temperature environments.
  • Keep away from strong magnetic fields and high voltage.
  • Clean with soft cloth only - no organic solvents.
  • Remove battery for long-term storage.
Frequently Asked Questions
Who are we?
Deko Corporation specializes in the development, manufacture and marketing of KM brand precision measuring tools in China mainland.
What products do we carry?
Our product line includes dial indicators, micrometers, calipers, bore gauges, height gauges, dial thickness gauges, depth gauges, bevel protractors,
gauge blocks, levels, and more.
What are the terms of trade?
We support FOB, CFR, CIF, and EXW trade terms.
What are the forms of payment?
We accept T/T, L/C, D/A, D/P, PayPal, and Western Union.
Do we accept customization?
Yes, OEM services are available.
How about after-sales service?
All products come with a one-year warranty. Defective parts will be replaced promptly. Our strict calibration and inspection processes
ensure reliable product quality.
